low oil consumption forklift with strong gradeability and smooth power ratation
Specifications:
| Model | XG560s | Height of Overhead Guard(mm) | 2504 |
| Rated lifting capacity (kg) | 6000 | Maximum Lifting Height(mm) | 3000 |
| Weight (kg) | 9300 | Free Lifting Height(mm) | 170 |
| Turning radius (mm) | 3400 | Minimum Ground Clearance(mm) | 245 |
| Fork: L x W x H(mm) | 1200x150x60 | Track (Front/rear)(mm) | 1530/1500 |
| Overall Dimensions (LxBxH) (mm) | 4720x2066x2599 | Front tyre | 4x8.25-20-14PR |
| Maximum Travel Speed (km/h) | 21.5 | Rear tyre | 2x8.25-15-14PR |
| Gradeability (%) | 20 | Engine Model | 6102BG4 |
| Load Center Distance(mm) | 600 | Engine Rated Power/Speed( kw/r • p • m) | 72.8/2200 |
| Tilt Angle of Mast (F/B) (°) | 6°/12° | Engine Max. Torque/Speed (N • m/r • p • m) | 353/1600-1800 |
| Wheelbase (mm) | 2280 |
Description:
Has heavy duty torque converter installed for smooth rotation of power within the internal combustion engine, to rotating driven load. Torque converter supersedes the mechanical clutch, effectively allowing the load to be configured from the power source.
Application:
Our forklift is widely used in logistics operation sites like port, wharf, industrial and mining enterprises, station and warehouse, construction site, log yard and much more.
Advantage:
1. The special features of these engines include sufficient power, large torque, large overload capacity, reliable operation, and low oil consumption and so on.
2. It has large torque flow force, strong gradeability, large frame rigidity, and it is resistant to impact, where it acts more like cross-country forklift.
3. Steering axle has less twisting hydraulic steering gear with transverse cylinder ensuring steering flexibility, maintenance simplicity and highly reliable.
4. Flexible internal transmission flow providing efficiency, reliable, stable and entire machine operation conveniences.
